KIJI 10

KIJI 10 refers to the B.E. Meyers KIJI K1‑10°, the wide‑beam (10°) version of their K1 VCSEL IR laser illuminator for 300‑series Scout‑style bodies.

What it is

• Class 3R VCSEL infrared illuminator head (no visible or aiming laser), using the same core tech as the MAWL‑DA.

• K1‑10° is the “flood” model with a 10° native beam; it ships with a 40° diffuser cap for very wide spill.

Key specs (K1‑10°)

• Max output: up to 350 mW IR, 850 nm wavelength.

• Power levels: four programmable PLs, typically 6 mW, 15 mW, 85 mW, 350 mW.

• Battery: 1x CR123A; about 1 h 12 min at full power constant‑on, plus ~46 min until output falls to 10% (≈35 mW).

• Range: designed to defeat photonic barriers with wide spill; practical illumination beyond ~175 m with the native 10° beam.
